XPE Foam Acoustic Underlay
XPE Acoustic underlay is a flexible cross linked closed cell polyolefin foam with good quality, medium density underlay for all floating floor applications.
Product Attachments:
Acoustic underlay
XPE acoustic foam
Floor underlayment sound insulation
Keywords: XPE Foam Acoustic Underlay
- DESCRIPTION
-
XPE foam acoustic underlayment is a popular choice for soundproofing flooring in homes and commercial spaces. This type of underlayment is made from cross-linked polyethylene foam, which is lightweight and flexible, making it easy to install under laminate, hardwood, or tile flooring.
The XPE foam material is designed to absorb impact noise and reduce sound transmission between floors, creating a quieter and more comfortable living or working environment. In addition to its acoustic properties, XPE foam underlayment also provides thermal insulation, helping to keep rooms warmer in the winter and cooler in the summer.
TECHNICAL PROPERTIES
PROPERTY VALUE Density 30 ±3 kg/m3 Colors Grey, black, blue (other colors on request) Size 1.0 m x 20 m, 1.2 m x 20 m Thickness 3, 5, 8, 10 mm (±0.5 mm tolerance) Max. load 400 kg/m2
Impact sound reduction improvement L 3 mm 5 mm 8 mm 10 mm 15 dB 17 dB 19 dB 21 dB Water Absorption by volume ≤ 0.1% Thermal condictivity ≤ 0.034 w/m*k (23 ± 2°C) Compression Strength(25%) ≥ 0.04 Mpa Resistance to Fungi Zero Growth Ozone Resistance Excellent UV Resistance Excellent (3000 hour QUV Exposure) Salt Resistance No change in performance Operating Tempreature Range -50 °C ~ +90 °C REACH Directives SVHC ≤ 0.07(Complies) Combustion performance Complies APPLICATION
SIZE & LOADING QUANTITY
03 mm x 1.2 m x 80 m, 188 rolls/40' HQ
05 mm x 1.2 m x 50 m, 188 rolls/40' HQ
08 mm x 1.2 m x 30 m, 188 rolls/40' HQ
10 mm x 1.2 m x 25 m, 188 rolls/40' HQ
